"KCOS" (Kyros Card Operating System)

Internally designed "KCOS" (Kyros Card Operating System) is a full-featured OS. It can be used for things like electronic purses and personal identification documents, as well as in the domains of transportation, banking, e-commerce, medicine (health and insurance), telecommunications, and even utility services.

The National Informatics Centre (NIC) -Government of India body creating standards-has established the "SCOSTA" Smart Card Operating system for Transport Application. Applications for both driver's licences and motor vehicle registrations will require this. This product is NIC-certified for use with the Phillips and Reneses chipsets, while an uncertified version is available for use with the Infineon and Samsung chipsets.

"KCOS" (Kyros Card Operating System) is a comprehensive Smart Card operating system developed in-house. Can be used in the fields of Transportation, Banking, E-Commerce, Medical (Health & Insurance) Telecommunications, Security Identification and Utility Services and several applications like electronic purse, Personal ID cards.

FEATURES

STANDARDS: Complies To ISO/IEC 7816 (4-9)/PCSC and SCOSTA

SECURITY: ISO/IEC 7816-8/9 And Offers Standard Algorithms For ENCRYPTION DES, T-DES, MAC Suitable For All DSA Functions.

MULTIPLE APPLICATIONS: Four-Layered File Management System. Offers Portability Of Different Applications On A Single Smart Card.

"KCOS-D" (Kyros Card Operating System): "SCOSTA" Smart Card Operating system for Transport Application as defined by NIC-Government of India body defining standards. This will be used for Driving License and Vehicle registration applications.

FEATURES:

  • ISO 7816-3, 4, 6, 8 & 9 compliant
  • Support for Multi applications.
  • Support for TDES algorithm.
  • Support for 32 keys & pins at each Directory level.

STANDARD SPECIFICATIONS:

File organization: 4 levels including MF

File Types:

  • 1. Binary
  • 2. Record type (fixed/variable) *TLV & NON TLV
  • 3. Linear (fixed /variable) *TLV & NON TLV
  • 4. Cyclic

Protocol: T= 0
Operating baud rate: 9600
Maximum Keys & Pins: 32 Keys & Pins at each level
Algorithms Support: TDES

DEVELOPMENT KITS SUPPORT: “YES”

Development Kit consists of the following:

1. Smart Card Reader: 1 No.
2. Drivers / Dll’s on CD 1 No.
3. Sample cards 10 Nos.

CHIP SPECIFICATIONS:

  • ISO 7816-3, 4, 6, 8 & 9 compliant
  • Support for Multi applications.
  • Support for TDES algorithm.
  • Support for 32 keys & pins at each Directory level.

Architecture: 8 Bit CMOS RISC controller
EEPROM: 4 KB
RAM: 1024 Bytes
Operating Voltage: 2.7 to 5.5 V

TARGET APPLICATIONS:

  • Driving License
  • Registration Certificate Book “RC-BooK”
  • Loyalty
  • E-Purse Card
  • Utility Services
