SMART MEMORY CARDS
Kyros Soft Tech Limited is proud to release "SMART-MEM" as a commitment to the smart card industry to provide affordable technology. The SMART-MEM is the world's first contact smart card with flash memory that is fully compliant with the T=O protocol.
SMART-MEM is intended to expedite and improve the integration of smart cards into a variety of applications without compromising security-based mechanisms such as authentication and verification.
SMART-MEM is available in three distinct flavours, providing integrators with a greater selection based on the application's specific requirements and the benefit of migrating from existing memory-based cards.
SMART-MEM-1
Available memory sizes:
4K / 8K / 16K / 20K / 24K / 32K / 48K / 64K / 128K
Fully byte addressable for all read / writes operations and offers secured code verification for all write operations.
SMART-MEM-2
Available memory sizes:
4K / 8K / 16K / 20K / 24K / 32K / 128K / 196K
It is the worlds only Data object oriented secured contact card which offers security of each and every Data Object created at the owner level, user level and the application level making it the most desirable and adoptable card for integrators.
SMART-MEM-3
Available memory sizes:
4K / 8K / 16K / 20K / 24K / 32K / 128K /196K
It comes with all the features of SMART-MEM-2 with TDES “Triple Data Encryption Standard”
Features:
- ISO 7816-3 compliant
- Support for Multi applications
- Support for TDES algorithm
- Support for keys & pins at each Data Object level
- E-Commerce
Standard Specification:
| Data organization: | Data Objects |
| Protocol: | T= 0 |
| Operating baud rate | 9600 |
Chip Specifications:
| Architecture: | 8 Bit CMOS controller |
| MEMORY: | FLASH 4KB to 256 KB |
| Operating Voltage: | 2.7 to 5.5 V |
Target Applications:
- Health
- Loyalty
- E-Purse Card
- Utility Services
Development Kit Support:
- Kyrotec’s Development Kit Consists of the following:
- a. Smart Card Reader: 1 No.
- b. Drivers / Dll’s / 1 No.
- c. Sample cards 10 Nos
- d. Sample application source code in C.D.
*Note: We provide our valued customers with a ready to use soft ware libraries & plug-ins that may be needed to expedite the development or deployment of solutions.
